Railway fish plate, also known as rail fish plate, rail joint bar, rail joints or splice bar, angle bar. It is a metal rod bolted to the ends of two rails to connect them together.
Kingrail Parts is a professional railway fish plate supplier, we can provide different kinds of fish plates. Such as: insulated fish plates, bulged fishplates(Joggled fish plates), compromised fish plates, damper fishplate, variable Cross-Section Fish Plate and glued insulated fishplates, etc.
Kingrail Parts has more than 20 years of production experience and is able to customize fish plates according to customer specifications and standards.
Specifications
|
Fishplate for UIC Standard Steel Rail |
|||
|
Steel Rail Type |
Steel Rail Weight (KG/M) |
Fishplate Standard |
Fishplate Material |
|
UIC54 |
54.43 |
UIC |
45#,55# |
|
UIC60 |
60.34 |
||
|
Fishplate for BS Standard Steel Rail |
|||
|
BS50'O' |
24.833 |
BS 47-1 |
55#,45# European Grade 700 |
|
BS60A |
30.618 |
||
|
BS75R |
37.041 |
||
|
BS80A |
39.761 |
||
|
BS90A |
45.099 |
||
|
BS100A |
50.182 |
||
|
BS113A |
56.398 |
||
|
Joint Bar for AREMA 2007 Standard Steel Rail |
|||
|
100RE(TR50) |
50.35 |
AREMA 2007 |
45#,55#, AREMA Grade Steel |
|
115RE |
56.9 |
||
|
115-119RE |
|||
|
132RE |
65.31 |
||
|
133RE |
66.1 |
||
|
136RE |
67.41 |
||
|
132-136RE |
|||
|
Fishplate For Chinese Standard Steel Rail |
|||
|
GB15KG |
15.2 |
YB226-63 |
Q235,45# |
|
GB18KG |
18.06 |
YB225-63 |
|
|
GB22KG |
22.3 |
YB14-63 |
|
|
GB24KG |
24.46 |
||
|
GB30KG |
30.1 |
YB351-63 |
|
|
GB38KG |
38.733 |
TB/T 2345-2008 |
45#,55# |
|
GB43KG |
44.653 |
||
|
GB50KG |
51.514 |
||
Why choose Kingrail Parts
1. The production plant covers an area of more than 100,000 square meters, with 220 workers and 20 technicians
2. Our railway products meet international standards such as BS, UIC, DIN, ASTM, AISI, etc.
3. Passed ISO9001-2008 certification
4. Customized according to your specific requirements.
5. Our railway products are exported to Asia, Europe, America, the United States, Germany, the United Kingdom, France, Thailand, Vietnam and other places.
Get more help
If you need fish plate, please contact us to get the latest quotation.
