Kingrail Parts is one of the most professional crane rail suppliers in China. We provide ASCE Rail of various specifications. High-quality.
Our ASCE crane rails are manufactured according to the American standard ASCE. ASCE rails have a T-shaped rail profile and flat bottom. ASCE rails are used in light cranes, mining tracks, automatic warehouses and other industrial applications.
ASCE Rail Specifications:
Type: Light Rail
Standard: United States (ASTM/AREMA)
Material: 900A/1100
ASCE crane rail main models: ASCE 12 crane rail, ASCE 20 crane rail, ASCE 25 crane rail, ASCE 30 crane rail, ASCE 40 crane rail, ASCE 50 crane rail, ASCE 60 crane rail, ASCE 70 crane rail, ASCE 75 crane rail, ASCE 80 crane rail, ASCE 85 crane rail.
In other words, we call them 12-lb/yd ASCE rails, 20-lb/yd ASCE rails, 25-lb/yd ASCE rails, 30-lb/yd ASCE rails, 40-lb/yd ASCE rails, 50- lb/yd ASCE rail, 60-lb/yd ASCE rail, 70-lb/yd ASCE rail, 75-lb/yd ASCE rail, 80-lb/yd ASCE rail, 85-lb/yd ASCE rail.
|
Size |
Head (mm) |
Height (mm) |
Base (mm) |
Web (mm) |
Nominal weight (kg/m) |
Material |
Length （m） |
|
ASCE 25 |
38.1 |
69.85 |
69.85 |
7.54 |
12.4 |
700 |
6-12 |
|
ASCE 30 |
42.86 |
79.38 |
79.38 |
8.33 |
14.88 |
700 |
6-12 |
|
ASCE 40 |
47.62 |
88.9 |
88.9 |
9.92 |
19.84 |
700 |
6-12 |
|
ASCE 50 |
54 |
98.4 |
98.4 |
11.11 |
24.855 |
700 |
6-12 |
|
ASCE 60 |
60.32 |
107.95 |
107.95 |
12.3 |
29.76 |
700 |
6-12 |
|
ASCE 75 |
62.71 |
122.24 |
122.24 |
13.49 |
37.2 |
900A/1100 |
12-25 |
|
ASCE 85 |
65.09 |
131.76 |
131.76 |
14.29 |
42.17 |
900A/1100 |
12-25 |
