Rail pads are elastic polyurethane pads that are sandwiched between the rails and the sleepers to protect the sleeper tops from wear and impact.
As a professional manufacturer of rubber track pads, we offer a full range of high-performance rubber track pads to meet stiffness requirements and various applications.our rubber pads are made according to E-type, SKL, KPO, NablaPR, Russia, fast, UIC, BS, JIS and other standards.
Types of Our Rail Pads
1. Rail pads for E-type rail fastening system
Railroad rubber pads for E-type railroad fastening systems have a similar function to railroad insulators, insulating the rail above them from the sleepers below them, effectively preventing vibration and structure-borne noise. Rail pads, e-type clips, rail insulators/insulation gauge blocks, rail shoulders/embedded parts together form a complete set of E-type rail fastening system
2. Rail pads for SKL rail fastening system
The rail pad in the SKL Rail Fastening System is a small but important fastener component that works with SKL clips, screw spikes, plastic dowels, tie plates and more. The elastic rail pads we produce have a defined stiffness and significantly increase the elasticity of the rail superstructure. With a higher level of resiliency, it contributes to the quiet operation of rolling stock to meet the acoustic requirements of today's railway lines.
3. Concrete sleeper rubber pad
Material: | rubber |
Standard: | TB/T2626-95 |
Application: | 43kg/m ,50kg/m, 60kg/m, 75kg/m rail |
Models: | 43-7-7, 43-10-7, 50-7-9, 50-10-9, 60-10-17, 60-12-17 |
Operation temperature: | -50~70 degrees |
Certificate: | ISO9001:2008 |
Notes: | Should be stored in clean, ventilated place. Don’t put under direct sunlight, and keep away from heat sources and chemical reagents. Don’t touch oil, organic solvent and other chemicals. |
4. High elastic slotted EVA/HDPE/rubber rail pad
Our EVA/HDPE/rubber rail pads have high elasticity and are suitable for rail types such as rail UIC54, UIC60, BS80lbs, BS100lbs, sizes are to order. Cushions with or without grooves can be customized according to customer requirements, in various possible designs.
