The rail rubber pad used in the E-rail fastening system has a similar function to the rail insulator, which can isolate the rail above it from the sleeper below it, effectively preventing vibration and structural noise. The rail pad, e clips, rail insulator and rail shoulder form a complete set of E-type rail fastening system.
2. Rail pad for SKL rail fastening system
The rail pad in the SKL rail fastening system is a small but important fastener component that works with SKL clips, screw spikes, plastic dowels, rail tie plates, etc. Rail rubber pads have a certain rigidity and significantly increase the elasticity of the rail superstructure. It has higher elasticity and helps rolling stock to run quietly to meet the acoustic requirements of today's railway lines.
3. Rubber pads for concrete sleepers
Material: rubber
Standard: TB/T2626-95
Application: 43kg/m, 50kg/m, 60kg/m, 75kg/m rail
Models: 43-7-7, 43-10-7, 50-7-9, 50-10-9, 60-10-17, 60-12-17
Operating temperature: -50~70 degrees
Certificate: ISO9001:2008
Note: Rail pads should be stored in a clean and ventilated place. Don't put it under direct sunlight, keep away from heat and chemical reagents. Do not touch oil, organic solvents and other chemicals.
4. High elastic groove EVA/HDPE/rubber rail pad
Our EVA/HDPE/rubber rail pads have high elasticity, suitable for UIC54, UIC60, BS80lbs, BS100lbs and other track types and order sizes. According to the customer's requirements, the pads with or without grooves can be customized, and various possible designs are adopted.
