The 60E1 (UIC60) rail is manufactured according to the European standard EN 13674-1. It is used for railway construction. This is a T-section rail (flat bottom rail) with a mass of 60.21 kg per meter.
UIC60 Rail is mainly used for heavy-duty railways, a very popular rail. It is widely used in high-speed railways in France and Germany.
UIC60 rail has the features of good ductility, high fatigue strength and moderate fracture toughness.
UIC60 Rail Specifications:
Size: 60E1 UIC60 rail
Weight: 60.21kg/m
Length: 5m~25m or other lengths according to customer requirements
Material: R200, R260, R260MN, R350HT
Standard: EN 13674-4
Hardness: R260, R320
Grade: 900A/1100
Type: Heavy Rail
Certificate: ISO9001:2008
UIC60 Rail Size:
| Type of Rail | Standard | Dimensions (mm) | Section S | Mass m | ||||
| H | B | C | D | E | cm² | kg/m | ||
| European standard EN 13674-1 | ||||||||
| 60E1 (UIC60) | EN 13674 - 1 | 172,00 | 150,00 | 72,00 | 51,00 | 16,50 | 76,70 | 60,21 |
Mechanical Properties of UIC60 Rail:
| Standard | Steel Grades | Mechanical Properties | ||
| Rm MPa | min A5 % | HB | ||
| EN 13674 - 1 (2006) | ||||
| R200 |
min 680 |
14 | 200 - 240 | |
| R260 |
min 880 |
10 | 260 - 300 | |
| R260 MN |
min 880 |
10 | 260 - 300 | |
| R350 HT |
min 1175 |
9 | 350 - 390 | |
UIC Rail Specifications:
|
Size |
Dimension(mm) |
Weight |
Material |
Length |
|||
|
Head(mm) |
Height(mm) |
Bottom(mm) |
Web(mm) |
||||
|
UIC50 |
70 |
152 |
125 |
15 |
50.46 |
900A/1100 |
12-25 |
|
UIC54 |
70 |
159 |
140 |
16 |
54.43 |
900A/1100 |
12-25 |
|
UIC60 |
70.4 |
172 |
150 |
16.5 |
60.21 |
900A/1100 |
12-25 |
