Rail clips are one of the common rail fasteners in the rail system. Under normal circumstances, elastic rail clips are made of forged spring steel. E1809 Rail Clip is one of E-type rail clips.
E rail clips provide reliable and long-lasting rail alignment under the harshest working conditions, thereby extending the service life of railway tracks.
E1809 Rail Clip Specifications:
Material: 60Si2MnA, 60Si2CrA, 55Si2Mn, 38Si7
Diameter: 16mm, 18mm, 20mm
Hardness: HRC 42-47
Standard: GB/T 1222, DIN 17221
Fatigue life: 5 million cycles without breaking
Surface: plain (oiled), oxidized black, painted
Application: rail fastening system
E Rail Clip Features:
1. Safe and reliable system
2. No need to check torque due to its self-tensioning design
3. A wide range of designs suitable for every application, environment and market segment
Rail Clip Production Process:
Shearing-heating to forging temperature-forming-quenching-tempering-inspection-packaging.
E Rail Clips series: E1609, E1804, E1806, E1809, E1817, E2001, E2003, E2005, E2006, E2007, E2009, E2039, E2055, E2056, E2096, etc.
SKL Rail Clips series: SKL1, SKL2, SKL3, SKL12, SKL14, etc.
PR Rail Clips: PR16mm, PR85, PR309, PR401, PR601, PR601A, etc.
Fastclip: 15mm, 16mm
Deenik Clip: 18mm
Gauge Lock Clip: 14mm
