A rail joint bar or rail fishplate is a metal bar bolted to the ends of two rails to join them together to form the rail.
Kingrail Parts can supply 60 LB ASCE rail splice bar with best price.
Specifications:
Material: 45# steel, 45Mn
Holes: 4 holes, 6 holes
Surface: Plain/Black Oil
Dimensions (L x W x H) (mm): 790/820mm
Producing process: Hot rolled
Application: 60 kg rail, P60 rail
Standard: TB/T 2345-2008
Packing: Bundled by steel strips with iron/wood pallets
|
Tee Rail |
A |
B |
C |
D |
E |
Bar (") Length |
Bar weight (PR) |
Bar Punching |
Common Type |
|
|
4-Hole |
6-Hole |
FxGxHxGxF |
||||||||
|
60 lb. ASCE |
2- 1/2 |
5 |
- |
1 |
1-115/128 |
20 |
27.2 |
- |
5 x 5 1/8 x 5 |
Angle F. T. |
We can customize rail joint bars according to customers' specifications and requirements
Manufacturing Process:
Raw material - hot rolling of steel bars - cut to length - reheat - drilling holes - cooling- inspection- packing.
Contact us
Please contact us for more information and quotations.
