Train cart wheels are an important part of rail vehicles. We produce most types of railway wheels, we can provide most of the international standard wheels, such as AAR M-208, AAR M-107, UIC 812-3, BS 5892-3, JIS E5402-2, IRS R34, TB /T 2817.
Train Cart Wheels Specifications:
1) Material: 60#, 65#, 65Mn, 42CrMoA
2) Surface and rim quenching hardness: HRC45-55
3) Trand surface and rim quenching depth: 15-18mm
4) Processing wheel diameter: Φ 300-2000mm
Types of Train Wheels
1.Wagon Wheels
Used for railway freight car bogies, its running speed can reach 120km/h, wheel load. Truck wheels usually use tread brakes.
There are usually two types of manufacturing, casting and rolling. Use basin wheel webs when casting. For rolling, the web is usually S-shaped.
The wheels are manufactured in compliance with TB/T 2817, AAR M-107/208, BS 5892-3 and EN 13262 standards.
2. Passenger car wheels
Used for railway passenger car bogies, the wheel running speed is about 120km/h or more, and the wheel load is lighter.
They usually use shaft disc brakes or wheel disc brakes.
The wheels of passenger cars are manufactured by rolling. According to different braking methods, the webs can be S-shaped, double S-shaped or straight.
The manufacturing process complies with manufacturing standards TB/T 2817/2708, AAR M-107, BS 5892-3 and EN 13262.
3. Locomotive wheels
There are two types of locomotive wheels: integral wheels and split wheels.
The diameter of locomotive wheels is larger than that of ordinary wheels, usually over 1000mm.
Comply with manufacturing standards TB/T 2817, AAR M-107/208, BS 5892-3, IRS R-34 and EN 13262.
